Service73LPG system in Škoda vehiclesSelf-study programmeProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�GB1For the first time in the history of the Škoda vehicles, the customer is offered a liquefied petroleum gas powered vehicle directly from the factory. Liquefied petroleum gas is also known as liquid gas or LPG (Liquefied Petroleum Gas). LPG has already been used for decades and is currently the world's most widely used alternative fuel. It is a clean-burning fuel, therefore making it one of the most modern energy carriers. In many big cities more and more vehicles run on LPG, which is largely due to the rising popularity of this fuel.Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�LPG consists of a mixture of propane, butane and additives. Compared to other fuels, the use of LPG results in significantly lower exhaust emissions. Overall, the emissions produced by liquefied LPG vehicles are among the lowest emissions achieved at present by internal combustion engines. The LPG fuel is virtually sulphur-free and the combustion takes place with almost no soot emissions. Pollutants such as carbon monoxide (CO), hydrocarbon (HC), nitrogen oxides (NOx) and other exhaust gas components, which pose adverse health and environmental risks, are significantly reduced.2GBContentsBrief presentation of the LPG system 4System components System overview834Safety concept36Engine management42Wiring diagram44Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�You will find the instructions for the installation, removal, repair, diagnosis and detailed user information in the repair manual, the diagnosis unit VAS 505x and in the onboard literature. The time for going to press was on the 07/2009. This brochure is not subject to update.GB3Brief presentation of the LPG systemThe main components of the LPG systemAll the component parts which are required for the gas operation are already installed during the production. The normal petrol operation remains unchanged. The LPG system consists of: - the gas control unit - the gas fuel tank filler neck - the LPG tank with integrated multi-function valve - the conversion button with the gas supply indicator and the switch for the fuel selection - the evaporator with the electromagnetic highpressure valve for the gas operation - the gas filter - the gas distributor strip with the gas injection valves and the sensor of the gas distributor strip.Gas fuel tank filler neckProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�LPG tank with integrated multi-function valveConversion button with the gas supply indicator and the switch for the fuel selection4GBConsequences of failure If one or more components or component parts in the LPG system fail, the system switches back to petrol operation. If a fault is indicated when restarting the engine, the system does not switch back to LPG operation instead it only operates in petrol mode. It is necessary to visit an authorised service workshop.Gas control unitEvaporator with electromagnetic highpressure valve for gas operationProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�Gas filterSP73_01Gas distributor strip with the gas injection valves and the sensor of the gas distributor stripGB5Brief presentation of the LPG systemThe 1.6 ltr./75kW Engine with 2-valve technologyThe 1.6 ltr. engine powered by LPG is based on the 1.6 ltr. Flex Fuel (E85) engine with the identification characters CCSA, which in turn is based on the technology of the 1.6 ltr. 75kW MPI engine with the identification characters BSE and is known from the Škoda Octavia II model range. There are no mechanical adaptations of the petrol engine CCSA necessary to enable LPG operation. The normal petrol operation remains unchanged and a switchover to LPG operation is possible using the conversion button in the centre console. In gas operation, the engine produces a power output of 72kW.Technical highlights 2-valve technology with roller rocker arm aluminium engine block with ribbed oil pan secondary air system plastic variable intake manifold modifi ed applications of the engine control unit, Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability adapted to the long-term gas operation with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.� - the valve drive, the cylinder head and the pistons with the piston rings were taken over from the Flex Fuel engine CCSASP73_02The gas-powered 1.6 ltr. engine must not be operated with ethanol (E85).6GBTechnical dataEngine identification character Design Number of cylinders Valves per cylinder Displacement Bore Stroke Compression ratio max. power output max. torque Engine management Fuel CHGA Inline engine 4 2 1595cm3 81mm 77.4mm 10.3 : 1 75kW at 5600 rpm - petrol 72kW at 5600 rpm - LPG 148Nm at 3800 rpm - petrol 144Nm at 3800 rpm - LPG Simos 7PP Super Unleaded RON 95 (Normal Unleaded RON 91 with low reduction in performance) LPG (liquefied petroleum gas) Exhaust after treatment Emission standard Main catalytic converter with lambda control EU4Torque and power output diagram200 180 160 140 120 M (Nm) 100 80 60 40 20 100 90 80 70 60 50 40 30 20 10P (kW)Petrol performance curve LPG performance curve Petrol torque curve LPG torque curve10003000 n (min-1)50007000SP73_03GBProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�7System componentsThe gas fuel tank filler neckThe gas fuel tank filler neck is located right next to the petrol tank filler neck under the petrol cap and is connected to the LPG tank via an LPG line.SP73_04The gas fuel tank filler neck is provided with a non-return valve. This allows the liquid LPG to flow in one direction and prevents the liquid LPG to flow in the opposite direction. The non-return valve opens under the fluid pressure when filling up.Non-return valveSP73_05Gas fuel tank filler neckProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�Screw cap8GBThe tank nozzle adapterIn various countries the liquefied gas pumps are fitted with different fuel nozzles, therefore keep in mind that so-called tank nozzle adapters must be used in order to connect the fuel nozzle to the gas fuel tank filler neck when refuelling the vehicle. Currently there are two connection systems which are the most common all over Europe. The ACME tank nozzle adapter and the Dish connector.ACME connectorDish connectorSP73_06SP73_07Czech Republic Belgium Denmark Germany France England Greece Ireland Luxembourg Hungary Protected by copyright. Copying for private or commercial purposes,Italy in part or in whole, is not permitted Poland unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability Scotland with respect to the correctness of information in this document. Austria Copyright by ŠKODA AUTO A. S.� Switzerland PortugalBoth tank nozzle adapters are components of the vehicle equipment.GB9System componentsThe fuelling processWhen refuelling, the fuel flows through a closed system (the fuel nozzle and the gas fuel tank filler neck). Refuelling with LPG is as easy and takes just as long as with petrol. The filled quantity of LPG is indicated in litres and shown on the pump display in the same way as for petrol. The maximum filling capacity of the LPG tank is approx. 80%, this ensures there is suf ficent room for the LPG to expand mainly at higher ambient temperatures. After opening the fuel flap, the screw cap is unscrewed from the gas fuel tank filler neck and the adapter is screwed in.SP73_08Remove the fuel nozzle from the pump.Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�SP73_09Screw the rotary head of the fuel nozzle onto the adapter. Squeeze the trigger of the fuel nozzle and engage the trigger lock.SP73_1010GBPress the start button on the petrol pump and hold it pressed until the tank is filled up.SP73_11When releasing the fuel nozzle, a small quantity of LPG escapes into the surrounding area from the outlet holes in the rotary head. The LPG which escapes has a very low temperature and frostbite may occur on contact with the skin. Therefore the outlet holes must not be touched when refuelling.Remove the rotary head of the fuel nozzle and the adapter from the gas fuel tank filler neck. Screw the screw cap onto the gas fuel tank filler neck.Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�SP73_12SP73_13The procedure described for connecting the fuel nozzle is valid for the ACME connector.GB11System componentsThe LPG linesThe fuel enters the fuel tank via the LPG lines and from there it flows to the engine. The LPG system is divided into a high-pressure area and a low-pressure area. The LPG lines consist of copper tubing with a PVC hose jacket in the high-pressure area and they consist of hoses made of special rubber in the low-pressure area.The following LPG lines are installed:1. from the gas fuel tank filler neck to the tank(high-pressure area)2. from the tank to the evaporator(high-pressure area)3. from the evaporator to the gas distributor strip with the gasinjection valves (low-pressure area) 4. from the gas distributor strip with the gas injection valves to the intake manifold (low-pressure area)- copper tubing (ø 8mm) + PVC hose jacket - pressure of 8-10bar - LPG in the liquid state - copper tubing (ø 6mm) + PVC hose jacket - pressure of 8-10bar - LPG in the liquid state - hoses made of special rubber - pressure of 0.1-2bar - LPG in the gaseous state - hoses made of special rubber - pressure of 0.1-2bar - LPG in the gaseous stateLPG lines which are damaged (e.g. after an accident) must be completely replaced.12Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�GBThe LPG tankThe toroidal LPG tank is installed in the spare wheel well.It is made from sheet steel with a thickness of 3.5mm. The LPG tank has a capacity of 55 litres. The LPG tank cannot be filled past 80% of its total volume, because the LPG expands with the increase of temperature. The filling level is temperature-dependent and can fluctuate. The LPG tank holds approx. 44 litres when the outside temperature is 15°C.SP73_58LPG tankCover with rubber sealMulti-function valveA multi-function valve is integrated in the LPG tank. It is located in the hollow space in the middle of the LPG tank. The hollow space is closed by a cover with a rubber seal, whereby a gastight box is created.Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�SP73_60LPG lines to the tankLPG lines to the engineGB13System componentsThe multi-function valve in the LPG tankThe multi-function valve combines the following functions in a single body: - the electromagnetic valve for the gas tank N495 - the cut-off valve - the overpressure safety valve - the sender for the gas supply indicator G707Electromagnetic valve for the gas tank N495Sender for gas supply indicator G707Cut-off valve Overpressure safety valveFloat Gas suction pipeSP73_51Position of the multi-function valve in the gas tankProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�SP73_5914GBThe electromagnetic valve for the gas tank N495The electromagnetic valve for the gas tank N495 is a component of the multi-function valve. The valve for the gas tank regulates the LPG flow from the gas tank to the evaporator in the engine compartment. The opening and closing functions of the valve are actuated by the gas control unit. When switching over to petrol operation or switching off the engine, in the event of a high severity accident (crash detection) or a loss of voltage supply, the valve closes automatically.SP73_38Function Valve closed Valve openedSpring Coil Armature Valve to the evaporatorSpring Coil Armature Valve to the evaporatorSP73_53SP73_54from the gas tankfrom the gas tankIn the de-energised condition, the valve armature is pushed into the valve seat by the spring force and thereby shuts off the gas inflow from the gas tank to the evaporator.If all the system requirements for the gas operation are fulfilled, the gas control unit energises the electromagnetic valve for the gas tank N495. The magnetic field of the coil, which is energised by the voltage, pulls up the armature against the spring force and the access to the evaporator is opened. If the LPG operation is terminated, the gas control unit cuts off the voltage supply to the valve for the gas tank. The valve is closed by the Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted spring force. unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liabilitywith respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�GB15System componentsThe cut-off valveThe cut-off valve is located on the valve pot of the LPG tank. It serves to interrupt the fuelling process. The filling process is interrupted once the tank has reached a filling level of 80%.Inflation pressure Upper piston Lower piston Outlet parts Spring Inlet duct SpringLower valve chamber Shut-off valveCam disc FloatSP73_62 SP73_63The upper and the lower pistons are forced down When the position of the float corresponds to a by the inflation pressure. The upper piston has filling level of 80%, the shut-off valve slips down the function of a non-return valve. The lower into the recess of the cam disc and thereby the piston opens to the outlet ports through which the shut-off valve closes. liquid LPG flows into the tank. In addition, there Now the liquid gas creates a pressure build-up is a small bore in the centre of the lower piston inside the lower valve chamber. This pressure through which the liquid LPG enters the tank via together with the spring force enable the lower the open shut-off valve. If the shut-off valve is piston to move up. At the same time the lateral open, no pressure can build up in the lower valve outlet ports are closed. The back pressure builds chamber. up and becomes the filling pressure, the dispensDepending on the filling level, the cam disc is er switches off and the upper piston closes the Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted rotated byunless means of a fl oat during the fi lling procduct by any means authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not inlet guarantee or accept liability of the spring force. with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.� ess. The cam disc operates the shut-off valve.16GBThe overpressure safety valveThe overpressure safety valve as well as the valve for the gas tank N495 and the cut-off valve are components of the multi-function valve. The valve prevents the rupture of the LPG tank caused by the build-up of excessive pressure in the tank, for example as a result of high temperatures.SP73_40It functions as follows When the pressure in the LPG tank exceeds the value of 27.5 bar, the pressure relief valve is mechanically opened by the gas pressure and the LPG escapes into the area of the multi-function valve. The gas is lead from here to underneath the rear-end of the vehicle through plastic vent hoses.LPG outlet portOverpressure safety valvePlastic vent hosesSP73_56GBProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�17System componentsThe sender for the gas supply indicator G707The sender for the gas supply indicator G707 is a component of the multi-function valve. The sensor measuring device is integrated in the area for LPG. The fluid level contained in the gas tank is displayed at two points: - above the display unit on the body of the multi-function valve and - on the fuel level display integrated in the conversion button (gas supply indicator G706) in the centre console.Display unit on the body of the multi-function valveElectrical connection to the gas control unitBody of multi-function valveProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�Gearbox unit Display unit with integrated magnetDisplaySP73_52Annular magnet on the shaft FloatFunction The float moves inside the gas tank depending on the filling level (as in the petrol tank). This thrust movement is converted to the rotational movement by means of a lever system in the gearbox unit when the filling level changes. The annular magnet located at the end of the shaft, which protrudes from the gearbox unit, rotates as a result of this. The shaft end with the annular magnet is integrated in a housing within the valve body. Another magnet can also be found in the display unit. Depending on the filling level, the two annular magnets have a certain position to each other. The two magnets are separated by an insulation gap within the valve body and thus form a contactless magnetic connection. This magnetic connection influences the position of the needle in the display unit, where the filling level of the gas tank can be read off. This movement transfer between the float and the needle, which is created by the magnetic field, does not exclude the risk of gas escape. The display of the filling level on the body of the multi-function valve only serves as a safety feature.18GBContactless magnetic connectionHousing in the body of the multifunction valveDisplay unitMagnet of the display unit Annular magnet on the shaftSP73_55Gas supply indicator G706 in the centre console∞Ω0ΩSP73_49Sender for gas supply indicator G707Gas control unit J659Gas supply indicator G706Function The driver is informed about the filling level by means of the gas supply indicator G706 integrated in the conversion button, which is located in the centre console in the passenger compartment. The sender for the gas supply indicator G707 (switchable resistor matrix according to the position of the magnets or the gas tank float) is energised by the gas control unit. Depending on the filling level in the gas tank, various 0 - ∞ ohm resistors can be used.Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�GB19System componentsThe evaporator (pressure regulator)The LPG is converted in the evaporator from the liquid to the gaseous aggregate state. In addition, the evaporator has the task to reduce the pressure of the LPG from approx. 10bar to 1bar above the pressure prevailing in the intake manifold. The pressure of the LPG is reduced in two stages in the evaporator. The pressure fluctuations can be better compensated for because of the twostage pressure reduction.SP73_14Technical highlights1st stageunless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability N372 with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�- two-stage pressure reduction from 3-10bar to - electromagnetic high-pressure valve for gas 1.6bar operation N372 with external connector and integrated filter element High-pres- internal cooling circuit to prevent moisture and sure valve for gas operation ice formation in the evaporator Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted2nd stage from 1.6bar to 1bar via the intake manifold pressure Inlet of the gas tank Outlet to the gas filterTechnical dataType Working pressure Max. working pressure Weight Operating volume flow Operating temperature Two-stage evaporator with diaphragm 0.95bar up to 1.1bar 3.5bar 1450g 40 kg/h from -20°C up to +120°C Intake manifold vacuum connection Cooling water, inlet Cooling water, outletSP73_15Every 90.000km, the evaporator must be checked for contamination. This inspection of the evaporator is carried out using the control screw. In case of contamination, the filter in the electromagnetic high-pressure valve N372 must be changed. Please observe the entries in ELSA for this purpose.20GBStructure The evaporator has two stages. Each stage contains an inner chamber, an outer chamber and a control chamber in which there is LPG. The LPG flows between the 1st stage and the 2nd stage via an over flow channel which connects both stages. In addition, each stage has a valve with a flap and a piston. The piston is screwed to the diaphragm. Each side of the evaporator has a spring chamber. A spring is located in each spring chamber. Atmospheric pressure prevails in the spring chamber of the 1st stage and intake manifold pressure prevails in the spring chamber of the 2nd Stage. Between the 1st and 2nd stage is a rubber seal that separates the cooling circuit from the LPG.1st stage Inflow from the high-pressure valve for gas operation N372 Diaphragm Flap Inner chamber Piston Spring2nd stage Over flow channel Outlet to the gas filter Diaphragm Inner chamber Flap Piston SpringSpring chamber Spring chamberProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�Control chamber Intake manifold vacuum connection Outer chamberControl chamberOuter chamberCooling water, inlet Rubber sealCooling water, outletSP73_16GB21System componentsFunctionInflow from the high-pressure valve for gas operation N372 Spring chamber1st stage The liquid LPG flows through the electromagnetic high-pressure valve for gas operation N372 with a maximum pressure of 10bar and then enters the inner chamber of the 1st stage. At the same time the valve flap of the inner chamber is opened. Then the liquid LPG passes through the outer chamber and enters the control chamber of the 1st stage. On its way, the liquid LPG expands and thus converts to the gaseous state. The diaphragm of the 1st stage is influenced by the preset spring on the side of the spring chamber and the atmospheric pressure prevailing in the spring chamber.Diaphragm Flap Spring Control chamber Inner chamber Outer chamberSP73_17Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�When the gas pressure in the control chamber exceeds 1.6bar, the spring is pressed together by means of the diaphragm. The piston screwed to the diaphragm operates the valve flap which shuts off the inflow from the electromagnetic high-pressure valve for gas operation N372. The LPG can continue to expand and flows through the over flow channel into the inner chamber of the 2nd stage.Over flow channelFlap (closed)PistonSP73_19Through this, the pressure which acts on the diaphragm in the control chamber drops again below 1.6bar. The spring presses on the valve flap by means of the piston. The valve opens and allows the inflow of the LPG from the electromagnetic high-pressure valve N372. In this way, the pressure of the LPG is reduced from maximum 10bar to 1.6bar.Flap (open)SP73_1822GBOver flow channel Spring chamber Diaphragm Flap Spring Intake manifold vacuum connection Control chamber Inner chamberSP73_212nd stage In the 2nd stage, the liquid LPG continues to expand and is reduced to an overpressure of 1bar above the intake manifold pressure. The LPG passes through the over flow channel from the outer chamber of the 1st stage and enters the inner chamber of the 2nd stage. At the same time the valve flap of the over flow channel is opened. As the gas expands, it flows through the outer chamber and enters the control chamber of the 2nd stage. The diaphragm of the 2nd stage is influenced by the preset spring on the side of the spring chamber and the intake manifold pressure prevailing in the spring chamber.Outer chamberWhen the gas pressure in the control chamber exceeds 1bar above the intake manifold overpressure, the spring is pressed together by means of the diaphragm. The piston screwed Flap (closed) topermitted the diaphragm operates the valve flap which Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability shuts off the inflow of the LPG from the over flow with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.� channel. The LPG can continue to expand and reaches the filter and the gas injection valves via the outlet. PistonSP73_22Flap (open)Through this, the pressure which acts on the diaphragm in the control chamber drops again below 1bar above the intake manifold pressure. The spring presses on the valve flap by means of the piston. The valve opens and allows the inflow of the LPG from the over flow channel.SP73_20GB23System componentsThe cooling circuit Structure The cooling circuit is located inside the evaporator. It is connected to the cooling circuit of the engine via both cooling water connections. The rubber seal in the evaporator divides the cooling circuit into the 1st and 2nd stage. The cooling water flows from the 1st to the 2nd stage via both transfer channels.SP73_24Transfer channel of LPG from the 1st to the 2nd stage 1st stage 2nd stageProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted Rubber seal unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�Transfer channels Cooling water Cooling water, inlet Cooling water, outletSP73_23Function When the LPG is down-regulated from 10bar to 1bar above the intake manifold pressure, the liquid LPG expands and thereby changes the aggregate state from liquid to gas. At the same time the gas and its surroundings cool down creating the so-called "cold expansion" effect, which could lead to the evaporator icing up. Therefore, the cooling circuit of the evaporator is connected to the cooling circuit of the engine before it is connected to the heat exchanger. In this way, the heated cooling water contained in the evaporator prevents ice formation.24GBThe electromagnetic high-pressure valve for gas operation N372The electromagnetic high-pressure valve for gas operation N372 is mounted on the evaporator housing and serves to interrupt the gas supply from the gas tank to the evaporator. A filter is integrated in the high-pressure valve. It is used to filter out the impurities in the liquid LPG in order to protect the sensitive component parts of the evaporator. The electromagnetic high-pressure valve for gas operation N372 operates in the same way as the valve for the gas tank N495. Function Valve closedValve seat SpringThe electromagnetic high-pressure valve for gas operation N372 is only operated by the gas control unit J659 during the LPG operation. When switching over to petrol operation or switching off the engine, in the event of an accident (crash detection) or a loss of voltage supply, the valve closes automatically and no LPG enters the evaporator.Valve openedProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in seat this document. Copyright by ŠKODA AUTO Valve Coil Spring CoilA. S.�to the evaporator Filter Armature from the gas tankto the evaporator Filter from the gas tank ArmatureSP73_25SP73_26In the de-energised condition, the valve armature is pushed into the valve seat by the spring force and thereby shuts off the access to the evaporator.If all the system requirements for the gas operation are fulfilled, the gas control unit energises the electromagnetic high-pressure valve N372. The magnetic field of the coil, which is energised by the voltage, pulls up the armature against the spring force and the access to the evaporator is opened. If the LPG operation is terminated, the gas control unit immediately turns off the valve.GB25System componentsThe gas filterThe gas filter is located between the evaporator and the gas distributor strip with the gas injection valves. It serves to protect the gas injection valves and filters micro-particles out of the gas.SP73_27Filter insertGas outlet, to the gas distributor stripGas inlet, to the evaporatorSP73_28The gas filter must be changed every 30.000km. When installing the gas filter, ensure that the marking of the flow direction on the filter corresponds to the flow direction of the gas.Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�26GBThe gas distributor strip with the gas injection valvesThe gas distributor strip is fitted on the intake manifold of the engine. Four electrically actuated gas injection valves as well as a sensor for the gas distributor strip G401, which measures the pressure and the temperature of the LPG, are integrated in the gas distributor strip. From the evaporator the LPG flows through the gas filter and enters the gas distributor strip. A precisely dosed quantity of gas flows out of the gas injection valves and passes through the rubber hoses to the intake manifold and then into the combustion chamber of each cylinder. The gas injection valves are actuated by the gas control unit.Sensor for gas distributor strip G401SP73_29Gas injection valves N366-N369If the gas injection valves are operating in the gas mode, this can be heard through rather loud clacking noises. In order to counter the increased noise level in the gas operation, a blanket insulator is fitted under the engine hood.SP73_30Gas distributor strip Gas outlet, to the intake manifold Electrical connection Gas injection Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability valve with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.� Gas inlet, to the filterSP73_31Gas inlet, to the filterConnection of sensor for gas distributor strip G401 Gas outlet, to the intake manifoldGas distributor stripGB27System componentsGas injection valves N366-N369The gas injection valves N366-N369 are installed in the gas distributor strip.Electrical connectionTechnical highlights - simple, stable structure of the magnetic valve - designed with relatively large coils to prevent the bonding of LPG - easy installation - long life (about 290 million cycles)Gas inletTechnical dataResponse time Operating temperature Max. working pressure 1.7 ms ± 0.2 -40°C up to +120°C 3bar Gas outletSP73_32Current [A]The gas injection valves are actuated by the gas control unit J659 using a pulse width modulation signal (PWM).Time [ms] Actuation of the valveProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�SP73_33Before operating in LPG mode, carry out a function test on the injection valves once per engine start. This means that the injection valves are actuated by the gas control unit and are briefly raised shortly before switching over from petrol to LPG mode. This is a safety measure against residues penetrating into the gas injection valve and it also prevents bonding.28GBFunction During the LPG operation, the gas injection valves blow the LPG which is in the gaseous state into the intake manifold of each cylinder.Not actuatedSpringPistonMagnetic coil Upper chamber Armature Gas inletThe gas injection valve is de-energized. The pressure spring pushes the piston with the armature and the sealing lip downwards and thus closes the gas outlet to the intake manifold. LPG flows through the gas inlet into the lower chamber and passes through the bores in the armature into the upper chamber of the gas injection valve. Through this, the same gas pressure acts on the armature in the upper and lower chamber. The pressure prevailing in the lower chamber prevents the armature with the sealing lip being pushed up counter to the spring force and the gas injection valve from opening the gas outlet.Lower chamber Gas outletSealing lipSP73_34ActuatedSpringPistonGas inletThe gas injection valves are actuated by the gas control unit using the PWM signal. The electrical connection and the magnetic coil are located in the valve housing. When the magnetic coil is energised, this generates a magnetic field. In the magnetic field the armature together with the Magnetic sealing lip are raised counter to the spring force coil of the pressure spring and the gas outlet opens. Protected by copyright. Copying for private commercial purposes, in part or upper in whole, is not permitted into the TheorLPG flows from the chamber unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTOin A. S. � lower chamber through the bores the armature Armature and then enters the intake manifold via the gas outlet.Lower chamberSealing lipGas outletSP73_35GB29System componentsThe sensor for the gas distributor strip G401The sensor for the gas distributor strip G401 is installed in the gas distributor strip. It serves to measure the pressure and the temperature of the LPG. The gas temperature and the gas pressure are used to calculate and control the opening times of the gas injection valves. The gas pressure signal also determines when it is required to switch back to petrol operation: - inadequate LPG in the gas tank - a pressure drop in the gas system - clogged gas filterSP73_36Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�30GBThe switch for the fuel selection E395 and the gas supply indicator G706The gas supply indicator G706 and the switch for the fuel selection (petrol, gas) E395 are integrated in a conversion button. This button is located in the centre console. The conversion button displays the following functions: - fuel selection petrol/gas - gas level in the gas tank (filling level) - signalling of fault functionsThe switch for the fuel selection E395 The switch for the fuel selection E395 is used to switch over from petrol to gas (or vice versa). It is also possible to switch between petrol and gas operation while the engine is running, even when the vehicle is in motion. The choice of fuel is indicated by the steady lightProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted ing up of the blue LED "ON" when in gas mode or unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability SP73_44 with respect to the of information in this document. Copyright by ŠKODA AUTO A. S.� the orange LED "OFF" when in correctness petrol mode. Switching over from the petrol to the LPG operation is performed if the following conditions are met: - adequate LPG in the gas tank - engine coolant temperature higher than 30°C - engine speed in driving mode higher than 1200 rpm Switching over from the LPG to the petrol operation is performed automatically in one of the following situations: - inadequate LPG in the gas tank - fault functionConversion button for fuel selection LED for petrol operationRow of LEDs for gas filling levelLED for gas operationThe gas supply indicator G706 The row of blue LEDs indicates the filling level of gas held in the tank. If the level of the liquid gas in the gas tank is very low, the red reserve LED comes on.GB31System componentsEngine start The engine start-up is always performed in petrol mode. If the vehicle is parked when in gas mode, the blue LED "ON" flashes quickly when restarting – this means that the system automatically switches over to gas mode once all the operating conditions are met.LPG tank empty If the LPG tank is empty, a slow intermittent beep sound is heard. Additionally, the orange LED "OFF" lights up and the blue LED "ON" flashes slowly. The system automatically switches over to petrol. To turn off the beep sound, the driver must press the conversion button. Thereafter, only the orange LED "OFF" for petrol operation remains lit.Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�32GBFault functions in the LPG system The fault functions can be divided into two categories: 1. A temporary malfunction During a brief period of full-throttle acceleration (for example when overtaking) the gas pressure is no longer adequate if the filling level in the gas tank is low. If the conditions for the gas operation are met during a "temporary malfunction" (in our example: the engine runs in the partial load range or the gas tank was refilled), the system switches over again to gas mode after operating the conversion button.2. A fault in the LPG system (e.g. if a disconnection of the gas injection valve is detected) If a "fault in the LPG system" is present, in our example if a disconnection of the gas injection valve is detected, it is not possible to switch over to LPG operation. Both categories of faults are detected by the system and an entry is made in the fault memory of the gas control unit J659. Thereby, the orange LED "OFF" lights up and the blue LED "ON" flashes quickly. In addition, a quick intermittent beep sound is heard. The system automatically switches over to petrol. To turn off the beep sound, the driver must press the conversion button. Thereafter, only the orange LED "OFF" for petrol operation remains lit.Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�You will find a detailed description of the operation and switch signalling for the fuel selection in the supplement – Vehicles with gas operation, provided in the user manual of the vehicle.GB33System overviewThe supply schemeIntake manifold vacuum line Cooling water, outlet Cooling water, inlet 5 64213Legend 1 2 3 4 Gas fuel tank filler neck Connection adapter Gas tank Multi-function valve of the gas tank - electromagnetic valve for the gas tank N495 - overpressure safety valve - cut-off valve - sender for gas supply indicator G707 5 6 7 8 9 10 11 Evaporator Electromagnetic high-pressure valve for gas operation N372 Gas filter Gas distributor strip Sensor for gas distributor strip G401 Gas injection valves N366-N369 Gas control unit J65934Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�GB101010109 7 814Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�111213SP73_3712 13 14Engine control unit J623 Switch for fuel selection E395 and conversion button with gas supply indicator G706 Intake manifoldLPG high-pressure line, approx. 10bar LPG low-pressure line, approx. 1bar above intake manifold pressure Vacuum line Cooling water line Sensor signal line Actuator signal lineGB35Safety conceptSafety concept of the LPG systemThe concept of the LPG system and all the components, the structure and the materials used ensure the highest possible reliability and protection against damage. The high standard of safety has been confirmed by a series of crash tests.Safety components of the LPG system:The gas fuel tank filler neck with the non-return valve The non-return valve prevents the gas flowing back after refueling.SP73_05The LPG tank The LPG gas tank is located in the spare wheel well and is therefore protected as best as possible against mechanical damage and weathering. It consists of 3.5 mm thick sheet steel, is heat resistant and meets the highest safety requirements. Each fuel tank is subjected six times to a safety test during the production and is provided with a serial number and a test certificate.SP73_43Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�36GBTo support the high reliability of LPG vehicles, the LPG is mixed with odourants. This allows even the smallest leaks of the LPG system to be perceived by sense of smell.The cut-off valve The cut-off valve automatically shuts off the inflow of LPG when refuelling once the gas tank has reached a filling level of 80%. This ensures that there is enough room in the gas tank for expansion during an increase of temperature. The valve also prevents the gas from flowing back after refuelling.SP73_39The overpressure safety valve The overpressure safety valve prevents the rupture of the LPG tank from the build-up of excessive pressure in the tank, for example as a result of high temperatures. As soon as the pressure in the tank exceeds 27.5bar, the valve opens mechanically and remains open until the pressure in the tank has returned to normal.SP73_40GBProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�37Safety conceptThe electromagnetic valve for the gas tank N495 The electromagnetic valve for the gas tank N495 automatically interrupts the gas supply when the engine is standing in still motion, when switching over to petrol operation as well as after detecting a high severity accident (crash detection).SP73_38High-pressure lines All the high-pressure lines and connecting elements are made of copper and run mainly outside the passenger compartment.SP73_41The electromagnetic high-pressure valve for gas operation N372 The electromagnetic high-pressure valve for gas operation N372 automatically interrupts the gas supply to the evaporator when the engine is standing in still motion, when switching over to petrol operation as well asfor after a highin part or in whole, is not permitted Protected by copyright. Copying privatedetecting or commercial purposes, unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability severity accident (crash detection). with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�SP73_4538GBLow-pressure lines In the low-pressure area, the LPG is transported through special rubber hoses which prevent that the low pressure lines are damaged through oscillations.SP73_42Gas injection valves N366-N369 The gas injection valves only open once they are actuated by the gas control unit J659 using the PWM signal.SP73_32GBProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�39Engine managementSystem overviewSensorsSender for gas supply indicator G707Switch for fuel selection (petrol, gas) E395Sensor for gas distributor strip G401Coolant temperature sender G62 Gas control unit J659Output stage N122Intake manifold pressure sender G71Legend Sensors for gas operation Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted Sensors for gas operation unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.� Sensors for gas operation Sensors for petrol operation Actuators for gas operation Actuators for petrol operation40GBActuatorsElectromagnetic valve for the gas tank N495Gas supply indicator G706Engine control unit J623Electromagnetic high-pressure valve for gas operation N372Gas injection valves N366-N369Injection valves N30-N33SP73_46Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�GB41Engine managementThe control unitsIn addition to the engine control unit J623, a gas control unit J659 which is installed in the battery box is required for actuating the LPG operation. The original wiring from the engine control unit to the petrol injection valves is interrupted and is provided with an electrical plug. The petrol injection signals are transmitted from this plug to the gas control unit, where they are used for the calculation of the gas injection times. To avoid a fault message in the engine control unit, due to an interruption in the wiring, the engine control unit receives the expected signals of the petrol injection valves by means of resistors in the gas control unit.Gas control unit J659 Engine control unit J623Connection interruptedPlug connection in cable harnessSP73_47Injection valves N30-N33Gas injection valves N366-N369Legend Earth PositiveProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�42GBThe gas control unit J659The gas control unit J659 controls the gas injection based on the signals of the sensors and the actuators. In this way, the engine operation meets the requirements for optimal efficiency and low emission.Engine control unit J623Gas control unit J659SP73_48Sensors and actuators of the engine control unit J623: - coolant temperature sender G62 - output stage N122 - intake manifold pressure sender G71 - gas injection valves N30-N33Sensors and actuators of the gas control unit J659: - sender for gas supply indicator G707 - gas supply indicator G706 - switch for fuel selection E395 - sensor for gas distributor strip G401 - electromagnetic valve for the gas tank N495 - electromagnetic high-pressure valve for gas operation N372 - gas injection valves N366-N369Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�Legend Input signal Output signal Earth PositiveThe engine control unit J623To ensure a safe vehicle start-up even after parking the vehicle in the LPG operation, the performance map data in the engine control unit J623 was adapted.GB43Function diagram of the LPG systemWiring diagramJ299SSSSSA G185 G79K G42 G71 N122V101 G476 FJ623Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�G61G186G187G188J338G130G39 G83G40Legend A E395 F G6 G39 G40 G42 G61 G62 G71 G79 G83 G130 G185 Battery Switch for fuel selection (petrol, gas) E395 Brake light switch Fuel pump for predelivery Lambda probe before catalytic converter Hall sender Intake air temperature sender Knock sensor 1 Coolant temperature sender Intake manifold pressure sender Accelerator pedal sender Coolant temperature sender at radiator outlet Lambda probe after catalytic converter Accelerator pedal position sender 2 G186 G187 G188 G401 G476 G706 G707 J17 J299 J338 J623 J659 N30 N31 N32 Throttle valve drive Throttle valve drive angle sender 1 Throttle valve drive angle sender 2 Sensor for gas distributor strip Clutch position sender Gas supply indicator Sender for gas supply indicator Fuel pumpe relay Secondary air pump relay Throttle valve module Engine control unit Gas control unit Injection valve for cylinder 1 Injection valve for cylinder 2 Injection valve for cylinder 344GBSJ17N372 G6 N30 N31 N32 N33N495G401J623J659Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�G62 G395 N366 N367 N368 N369 G706 G707 K-LPGSP73_50N33 N122 N366 N367 N368 N369 N372Injection valve for cylinder 4 Output stage Gas injection valve 1 Gas injection valve 2 Gas injection valve 3 Gas injection valve 4 Electromagnetic high-pressure valve for gas operation N495 Electromagnetic valve for the gas tank V101 Secondary air pump K Diagnostic connection K-LPG Diagnostic connection for the LPG operation S Fuse 1 CAN data bus 2 CAN data busPositive Earth Input signal Output signal CAN data busGB45RemarksProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�46GBProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. S.�GB47List of Self-Study Programmes so farNo.1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50TitleNo.TitleMono-Motronic 51 2.0 ltr./85 kW petrol engine with balancing shaft and Central locking two-stage suction line Vehicle alarm 52 ŠkodaFabia; 1.4 ltr. TDI engine with unit injection Working with electrical plans system ŠKODA FELICIA 53 ŠkodaOctavia; Vehicle presentation Safety of the ŠKODA vehicles 54 ŠkodaOctavia; Electrical Components Principles of ABS - not published 55 FSI petrol engines; 2.0 ltr./110 kW and ABS - FELICIA 1.6 ltr./85 kW Protection against starting with transponder 56 Automatic gearbox DSG-02E Air conditioning in the vehicle 57 Diesel engine; 2.0 ltr./103 kW TDI with pump-nozzle Air conditioning FELICIA unit, 2.0 ltr./100 kW TDI with pump-nozzle unit 1.6 engine - MPI 1AV 58 ŠkodaOctavia, Chassis and electromechanical Four-stroke diesel engine power-assisted steering Power-assisted steering 59 ŠkodaOctavia RS, 2.0 ltr./147 kW FSI turbo engine ŠKODA OCTAVIA 60 2.0 ltr./103 kW 2V TDI diesel engine; solid particle 1.9 ltr. TDI diesel engine filter with additive ŠKODA OCTAVIA Convenience electronic system 61 Radio navigation systems in the Škoda ŠKODA OCTAVIA mech. gearbox 02K, 02J 62 ŠkodaRoomster; Vehicle presentation – part l 1.6 ltr. and 1.8 ltr. petrol engines 63 ŠkodaRoomster; Vehicle presentation part ll Automatic gearbox - fundamentals 64 ŠkodaFabia II; Vehicle presentation Automatic gearbox 01M 65 ŠkodaSuperb II; Vehicle presentation part l 1.9 ltr./50 kW SDI diesel engines, 66 ŠkodaSuperb II; Vehicle presentation part ll 1.9 ltr./81 kW TDI 67 2.0 ltr./125 kW TDI diesel engine with Common Rail 1.8 ltr./110 kW andby 1.8 ltr./92 kW for petrol Protected copyright. Copying privateengines or commercial purposes, in part or in whole, issystem not permitted injection unless authorised by ŠKODA AUTO A. S. ŠKODA AUTO A. S. does not guarantee or accept any liability OCTAVIA, CAN BUS data logger 68 1.4 ltr./92 kW with respect to the correctness of information in this document. Copyright by ŠKODA AUTO A. TSI S.� petrol engine with turbo drive OCTAVIA - CLIMATRONIC 69 3.6 ltr./191 kW FSI petrol engine OCTAVIA - Vehicle safety 70 All-wheel drive with Haldex coupling of the lV OCTAVIA - 1.4-ltr./44 kW engine and gearbox 002 generation OCTAVIA - ESP - fundamentals, design, functions 71 ŠkodaYeti; Vehicle presentation part l OCTAVIA 4 x 4 - all-wheel drive 72 ŠkodaYeti; Vehicle presentation, part ll 2.0 ltr. 85 kW and 88 kW petrol engines 73 LPG system in Škoda vehicles Radio navigation system - design and function ŠKODA FABIA - technical information ŠKODA FABIA - electrical units ŠKODA FABIA - electro-hydraulic power-assisted steering 1.4-ltr. - 16 V 55/74 kW petrol engines ŠKODA FABIA - 1.9 ltr. TDI Unit injection Mechanical gearbox 02T and 002 ŠkodaOctavia; model 2001 Euro-On-Board-Diagnosis Automatic gearbox 001 Six-speed gearbox 02M ŠkodaFabia - ESP Emissions in the exhaust gases Extended service intervals Three-cylinder petrol engines 1.2 ltr. ŠkodaSuperb; Vehicle presentation; part l ŠkodaSuperb; Vehicle presentation; part ll ŠkodaSuperb; 2.8-ltr./142 kW V6 petrol engine ŠkodaSuperb; 2.5 ltr./114 kW TDI V6 diesel engine ŠkodaSuperb; automatic gearbox 01VOnly for the internal use in the service network ŠKODA. All rights reserved. Subject to technical modifications. S00.2002.73.20 Technical status 07/2009 GB © ŠKODA AUTO a.s. http://portal.skoda-auto.com48This paper was made out of chlorine-free bleached cellulose.GB73
